EN 1.4116 Stainless Steel Rod
PREMIER EN 1.4116 STAINLESS STEEL ROD Manufacturer in China
EN 1.4116 is a high-carbon martensitic stainless steel engineered for superior performance where exceptional corrosion resistance and high hardness are critical. The inclusion of molybdenum and vanadium in its composition enhances strength, wear resistance, and toughness. This specific grade is celebrated for its ability to achieve and maintain an excellent, sharp edge. This martensitic stainless steel offers a robust, reliable, and high-performance solution for a wide range of demanding sectors. The material’s unique balance of properties delivers both lasting durability and a refined, professional finish that meets stringent quality standards.
Discover our top-quality EN 1.4116 stainless steel rod products here.
-
Characteristics of EN 1.4116 Stainless Steel
- Exceptional Corrosion Resistance: With a high chromium content of 14-15%, this steel offers outstanding resistance to rust and corrosion.
- High Hardness and Excellent Edge Retention: Through appropriate heat treatment, EN 1.4116 can achieve a Rockwell hardness of 55-59 HRC.
- Superior Wear Resistance: The inclusion of carbon, along with elements such as vanadium and molybdenum, provides this steel with high resistance to wear and abrasion.
- Excellent Toughness: EN 1.4116 offers a good balance of hardness and toughness, enabling it to withstand impacts and resist chipping or breaking under stress.
- Ease of Sharpening: Despite its good edge retention, this steel is relatively easy to sharpen when needed.
- Hygienic and Food-Safe: Due to its excellent corrosion resistance, EN 1.4116 is a food-safe material that is easy to clean and maintain, preventing the buildup of bacteria.
- Versatile Applications: This steel is highly adaptable, finding use in a wide range of products, including high-end kitchen knives, surgical and medical instruments, and various industrial cutting tools.
- Good Machinability: EN 1.4116 exhibits good machinability, enabling the precise and efficient manufacturing of complex parts and components.
EN 1.4116 Stainless Steel Technical Specifications
| Element | Content (%) |
|---|---|
| Carbon (C) | 0.45 - 0.55 |
| Chromium (Cr) | 14.0 - 15.0 |
| Molybdenum (Mo) | 0.5 - 0.8 |
| Vanadium (V) | 0.1 - 0.2 |
| Silicon (Si) | 1.0 max |
| Manganese (Mn) | 1.0 max |
| Phosphorus (P) | 0.04 max |
| Sulfur (S) | 0.03 max |
| Property | Metric (Hardened & Tempered Condition) |
|---|---|
| Hardness, Rockwell C | 55 - 58 HRC |
| Tensile Strength | ~750 - 900 MPa |
| Yield Strength (0.2%) | ~430 MPa |
| Elongation at Break | >12% |
| Property | Value |
|---|---|
| Density | ~7.7 g/cm³ |
| Melting Point | 1470-1500 °C |
| Modulus of Elasticity | ~215 GPa |
| Thermal Conductivity | ~30 W/m-K at 100°C |
- AISI: A close equivalent is 440A.
- JIS: Comparable to SUS 440A.
- AFNOR: Z50CD15
- GB: 5Cr15MoV
Common Applications of EN 1.4116 Stainless Steel
Cutlery & Food Processing
Surgical & Medical Instruments
Industrial Tools & Components
Outdoor & General-Purpose Knives
-
EN 1.4116 Stainless Steel Rod Customization
Beyond our standard inventory, we offer a full suite of processing services to provide EN 1.4116 stainless steel rods that precisely match your project specifications.
- Custom Cut-to-Length: We provide precision cutting and shearing services to deliver rods in the exact lengths required for your specific application, minimizing waste and preparation time.
- Diameter and Shape Range: Our EN 1.4116 rods are available in a comprehensive range of diameters and shapes, including round, square, and hexagonal, to suit various design and functional needs.
- Surface Finishing: Select from a variety of surface finishes to achieve the desired aesthetic and performance characteristics, including centerless ground for tight tolerances, smooth peeled, or highly polished for a mirror-like appearance.
- Precision Machining: We offer extensive value-added machining services, including CNC turning and milling, drilling, threading, and tapering to create fully finished components ready for assembly.
Contact our expert team to discuss your custom fabrication and machining requirements.
Contact Us
The performance of your tools and components hinges on exceptional materials. We supply high-grade EN 1.4116 stainless steel rods that meet stringent industry standards, ensuring superior hardness, corrosion resistance, and durability for your application. As your trusted supplier, we leverage our extensive stock and precision processing capabilities to meet your exact specifications, from standard lengths to fully machined custom parts. We don’t just supply steel; we deliver a commitment to uncompromising quality and performance for your most critical projects.
Ready to proceed? Contact our technical team for a comprehensive, no-obligation quote and expert material consultation. We are here to review your technical requirements and provide a tailored solution with competitive pricing and reliable delivery. Let us streamline your procurement process and help bring your project to fruition with the support it deserves. Send your inquiry now to secure the high-performance materials you need.
