ASTM A276 304 (UNS S30400) Stainless Steel Rod
Top 304 Stainless Steel Rod Manufacturer in China
The ASTM A276 304 (UNS S30400) stainless steel rod offers better corrosion resistance, excellent weldability, and extreme durability. Being versatile and high-performing, it is suitable for demanding applications in food processing, chemical production, and architectural projects. This stainless steel rod is highly corrosion-resistant in an aggressive atmosphere while maintaining its strength and polish, making it ideal for use both structurally and decoratively. The ASTM A276 304 (UNS S30400) stainless steel rod features a smooth finish, providing ease of machinability and utmost reliability for those seeking a high-quality material. This material elevates your project with a design that ensures lasting performance.
Discover high-quality 304 stainless rod products here.
-
Characteristics of 304 Stainless Steel
- Corrosion Resistance: Excellent resistance to oxidizing acids, salt spray, and various chemicals, making it ideal for diverse environments.
- High Ductility: Offers superior drawing, forming, and spinning properties, suitable for complex shapes and applications.
- Weldability: Easily welded using common methods, with minimal risk of carbide precipitation in low-carbon variants.
- Non-Magnetic Nature: Essentially non-magnetic in annealed condition, becoming slightly magnetic when cold worked.
- Temperature Resistance: Maintains strength and toughness at elevated temperatures, suitable for heat-intensive applications.
- Aesthetic Appeal: Attractive, easy-to-clean surface, widely used in decorative and architectural applications.
- Mechanical Strength: Balanced strength and elongation properties, ensuring durability and reliability in structural uses.
- Versatile Applications: Used in kitchenware, food processing, chemical equipment, and marine environments due to its robust properties.
ASTM A276 304 (UNS S30400) Stainless Steel Technical Specifications
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.045 max |
| Sulfur (S) | 0.030 max |
| Silicon (Si) | 1.00 max |
| Chromium (Cr) | 18.00 - 20.00 |
| Nickel (Ni) | 8.00 - 11.00 |
| Property | Value (Hot-Finished) | Value (Cold-Finished) |
|---|---|---|
| Tensile Strength, min | 75 ksi (515 MPa) | 90 ksi (620 MPa) |
| Yield Strength, min | 30 ksi (205 MPa) | 45 ksi (310 MPa) |
| Elongation, min | 40% | 30% |
| Reduction of Area, min | 50% | 40% |
| Property | Value |
|---|---|
| Density | 8,000 kg/m³ |
| Elastic Modulus | 193 GPa |
| Thermal Conductivity | 16.2 W/m·K (at 100°C) |
| Specific Heat Capacity | 500 J/kg·K |
| Electrical Resistivity | 720 nΩ·m |
| Coefficient of Thermal Expansion | 17.2 µm/m·°C (0-100°C) |
- GOST: 08Х18Н10
- UNS: S30400
- EN: X5CrNi18-10
- JIS: SUS 304
- BS: 304S31
- AFNOR: Z7CN18-09
Common Applications of 304 Stainless Steel Rod
Food Processing Equipment
Architectural Components
Automotive and Aerospace
Marine Applications
-
304 Stainless Steel Rod Customization
Beyond standard stock, we provide comprehensive processing services to deliver products that meet your exact project requirements.
- Custom Dimensions: Available in various lengths and diameters, ranging from 4mm to 500mm, tailored to specific project requirements.
- Thickness Range: Offered in thicknesses from 2mm to 150mm, accommodating diverse industrial applications and structural needs.
- Surface Finishing: Options include bright polished, matte, rough turned, and NO.4 finishes, ensuring aesthetic and functional versatility.
- Processing Services: Includes cutting, drilling, CNC machining, sandblasting, heat treatment, and anti-rust coating for enhanced usability and performance.
Contact our technical team to discuss your custom fabrication needs.
Contact Us
Experience the unmatched versatility and strength of the ASTM A276 304 (UNS S30400) Stainless Steel Rod. Suitable for use in various industries, it boasts high resistance to corrosion and heat. Set parameters for your order, specifying size, thickness, and an above-average surface finish. This type of stainless steel rod is widely used in food processing, construction, and marine applications, ensuring clients of utmost performance and reliability. Additional processing can include services such as cutting and CNC machining, designed to meet your specific needs.
Ready to begin? Contact our expert team for a detailed, no-obligation quote and professional material consultation. We are here to discuss your technical requirements and provide a tailored solution with competitive pricing and on-time delivery. Let us simplify your procurement process and help bring your project to life with the support it deserves. Send your inquiry now to secure the premium materials you need.
