EN 1.4662 / UNS S44660 Stainless Steel Sheet
Top EN 1.4662 / UNS S44660 Stainless Steel Sheet Manufacturer in China
EN 1.4662 / UNS S44660 is a premier super-ferritic stainless steel specifically engineered to thrive in aggressive, corrosive environments where conventional steels falter. Its formulation, significantly enriched with chromium and molybdenum, provides exceptional resistance to chloride-induced pitting, crevice corrosion, and stress corrosion cracking (SCC). The ferritic structure of this alloy imparts a unique combination of beneficial properties. These characteristics make EN 1.4662 / UNS S44660 a cost-effective and high-performance solution for a wide range of applications, including condenser and feedwater heater tubing, desalination systems, and heat exchangers in the chemical, petrochemical, and power generation industries.
Discover high-quality EN 1.4662 / UNS S44660 stainless sheet products here.
-
Characteristics of EN 1.4662 / UNS S44660 Stainless Steel
- Exceptional Chloride Corrosion Resistance: Outperforms standard grades with high Cr/Mo for superior seawater/chloride resistance.
- Excellent Thermal Properties: The alloy exhibits higher thermal conductivity and a lower coefficient of thermal expansion compared to austenitic stainless steels.
- High Mechanical Strength and Stiffness: The ferritic structure provides high inherent strength and a high modulus of elasticity.
- Good Weldability: Stabilized with Ti/Nb to prevent weld zone corrosion, maintaining post-fabrication integrity.
- Cost-Effective and Nickel-Free: Nickel-free EN 1.4662 provides cost stability compared to high-Ni alloys for compatible applications.
- Good Formability and Ductility: High strength with good formability for complex industrial components
- Superior Erosion Resistance: This grade has a higher resistance to erosion from water droplets and steam compared to other materials.
- Resistance to Hydrogen Embrittlement: Self-recovering from hydrogen embrittlement, ensuring reliable performance in critical process environments.
EN 1.4662 / UNS S44660 Stainless Steel Technical Specifications
| Element | Content (%) |
|---|---|
| Chromium (Cr) | 25.0 - 28.0 |
| Molybdenum (Mo) | 3.0 - 4.0 |
| Nickel (Ni) | 1.0 - 3.5 |
| Manganese (Mn) | 1.00 max |
| Silicon (Si) | 1.00 max |
| Carbon (C) | 0.030 max |
| Phosphorus (P) | 0.040 max |
| Sulfur (S) | 0.030 max |
| Nitrogen (N) | 0.040 max |
| Titanium + Columbium (Ti+Cb) | 0.20 - 1.00 |
| Property | Value |
|---|---|
| Tensile Strength, min | 585 MPa |
| Yield Strength (0.2% offset), min | 450 MPa |
| Elongation, min | 18 - 20% |
| Hardness, Brinell (max) | 241 - 265 |
| Property | Value |
|---|---|
| Density | 7.7 g/cm³ |
| Modulus of Elasticity | 210 GPa |
| Thermal Conductivity (at 20°C) | 17 W/m-K |
| Coefficient of Thermal Expansion (20-100°C) | 11 µm/m-K |
- ASTM: A176, A240, A268, A959
- UNS: S44660
- EN / DIN: 1.4662, X1CrNiMoNb28-4-2
- ASME: SA-240, SA-803
- Common Name: 26-3-3
Common Applications of EN 1.4662 / UNS S44660 Stainless Steel
Power Generation & Heat Exchangers
Desalination & Water Treatment
Chemical & Petrochemical Processing
Pulp & Paper Industry
-
EN 1.4662 / UNS S44660 Stainless Steel Sheet Customization
Beyond our standard inventory, we provide comprehensive processing services to deliver EN 1.4662 / UNS S44660 super-ferritic stainless steel products that meet your precise engineering requirements.
- Precision Cutting to Specification: We offer advanced cutting services to match your specific length and width needs.
- Custom Thickness and Forms: Our super-ferritic steel is available in a wide range of thicknesses suitable for various applications, from thin-gauge heat exchanger tubing to heavy-duty plate for vessel construction.
- Specialized Surface Preparation: Choose from various surface conditions to meet your application’s demands.
- Advanced Fabrication Support: We provide value-added fabrication services including tube forming, bending, and expert welding.
Contact our technical team to discuss your custom fabrication needs.
Contact Us
The integrity of your high-performance equipment hinges on the selection of advanced materials. We supply certified EN 1.4662 / UNS S44660 super-ferritic stainless steel sheets that meet the strictest industry standards, ensuring unparalleled performance in high-chloride and corrosive environments. As your dedicated partner, we utilize our extensive inventory and precision processing services to meet your exact specifications, from standard stock to fully customized components. We deliver not just a product, but a promise of exceptional quality and durability for your most critical projects.
Ready to begin? Contact our expert team for a detailed, no-obligation quote and professional material consultation. We are here to analyze your technical challenges and provide a tailored solution with competitive pricing and reliable on-time delivery. Let us simplify your procurement process and help bring your project to life with the superior material performance it demands. Send your inquiry now to secure the advanced super-ferritic steel you need.
