EN 1.4547 / UNS S31254 Stainless Steel Sheet
Top EN 1.4547 Stainless Steel Sheet Manufacturer in China
The UNS S31254 grade steel sheet is also known as 1.4547. It is a high-alloyed, super-austenitic steel with a remarkably high resistance to corrosion in aggressive chloride environments, such as seawater. Stainless steel, with its interruption and distinctive cavitation corrosion resistance, is thus best suited for use in marine, chemical, and offshore activities. The possibilities of this are ordinary in terms of industrial applications of steel, considering it is fully weldable and easily formable.
Discover high-quality EN 1.4547 stainless sheet products here.
-
Characteristics of EN 1.4547 Stainless Steel
- Exceptional Corrosion Resistance: Designed for halide-rich environments like seawater, ensuring durability against aggressive conditions.
- High Alloy Composition: Contains chromium, molybdenum, and nitrogen, offering superior pitting and crevice corrosion resistance.
- High Strength and Ductility: Combines moderate tensile strength with excellent ductility for demanding industrial applications.
- Excellent Weldability: Supports conventional welding methods with low heat input, ensuring strong and durable joints.
- Good Formability: Easily cold and hot formed, suitable for complex shapes and industrial fabrication needs.
- Resistance to Stress Corrosion Cracking: Performs well in environments prone to chloride-induced stress corrosion cracking.
- Versatile Industrial Applications: Ideal for marine, offshore, chemical, and food industries due to its robust properties.
- Durability in Extreme Conditions: Engineered to withstand high-intensity applications, ensuring long-term performance and reliability.
EN 1.4547 / UNS S31254 Stainless Steel Technical Specifications
| Element | Minimum (%) | Maximum (%) |
|---|---|---|
| Chromium (Cr) | 19.5 | 20.5 |
| Nickel (Ni) | 17.5 | 18.5 |
| Molybdenum (Mo) | 6 | 6.5 |
| Nitrogen (N) | 0.18 | 0.25 |
| Copper (Cu) | 0.5 | 1 |
| Carbon (C) | -- | 0.02 |
| Silicon (Si) | -- | 0.7 |
| Manganese (Mn) | -- | 1 |
| Phosphorus (P) | -- | 0.03 |
| Sulfur (S) | -- | 0.01 |
| Iron (Fe) | Balance | Balance |
| Property | Value | Unit |
|---|---|---|
| Tensile Strength (min | 655–850 | MPa |
| Yield Strength (0.2%, min) | 310–320 | MPa |
| Elongation (min) | 35–40 | % |
| Hardness (max) | 223 | HB |
| Impact Strength (typical) | 74 | ft-lb |
| Property | Value | Unit |
|---|---|---|
| Density | 8 | g/cm3 |
| Modulus of Elasticity | 195 | GPa |
| Thermal Conductivity | 14 | W·m⁻¹·K⁻¹ |
| Specific Heat Capacity | 500 | J·kg⁻¹·K⁻¹ |
| Electrical Resistivity | 0.85 | µΩ·m |
- ASTM: A240, A276, A479, F44
- UNS: S31254
- EN: X1CrNiMoCuN20-18-7
- SS: 2378
- AFNOR: Z1 CNDU 20.18.06Az
Common Applications of EN 1.4547 Stainless Steel
Marine Environments
Chemical Processing
Oil and Gas Industry
Food Industry
-
EN 1.4547 Stainless Steel Sheet Customization
Beyond standard stock, we provide comprehensive processing services to deliver products that meet your exact project requirements.
- Custom Dimensions: Sheets are available in tailored lengths and widths to meet specific project requirements and applications.
- Thickness Range: Offered in a variety of thicknesses, typically ranging from 0.5 mm to 50 mm, for diverse industrial needs.
- Surface Finishing: Available in finishes like brushed, polished, or matte to suit aesthetic and functional requirements.
- Processing Services: Includes cutting, welding, and forming services to deliver ready-to-use components for specialized applications.
Contact our technical team to discuss your custom fabrication needs.
Contact Us
Utilize EN 1.4547 / UNS S31254 Stainless Steel Sheet in ocean engineering, the chemical industry, and various other sectors due to its high resistance to corrosion, as well as its high power. In most hard-wearing tasks, we have stainless steel sheets more than we could ever need. Reach out today with an inquiry or to place an order!
Ready to begin? Contact our expert team for a detailed, no-obligation quote and professional material consultation. We are here to discuss your technical requirements and provide a tailored solution with competitive pricing and on-time delivery. Let us simplify your procurement process and help bring your project to life with the support it deserves. Send your inquiry now to secure the premium materials you need.
