AA 5052 (EN AW-5052) Aluminum Alloy Sheet
Top 5052 (EN AW-5052) Aluminum Alloy Sheet Manufacturer in China
AA 5052 Aluminum Alloy Sheet is a high-grade and non-heat-treatable alloy with excellent corrosion resistance characteristics and excellent fatigue strength, along with its good workability. This, with magnesium as the primary alloying element (from 2.2 to 2.8) and a slight chromium addition (0.15 to 0.35), offers a splendid mix of strength and corrosion resistance for a wide application spectrum.”
Discover high-quality AA 5052 (EN AW-5052) Aluminum Alloy Sheet products here.
-
Characteristics of 5052 (EN AW-5052)Aluminum Alloy
- Highly Resistant To Corrosion: It is highly resistive to marine and industrial atmospheres, making it perfectly suited for extremely corrosive environments.
- High Fatigue Strength: The material has enhanced endurance against repeated stress and is suitable for treatment in structures under vibration.
- Good Weldability: Surface welding during this process is readily accomplished; the alloy welds easily using all current welding techniques, including TIG and MIG, with little crack susceptibility.
- Excellent Workability: It is easily cold-formed and worked into desired configurations, which leaves ample leisure for manufacturing.
- Medium High Strength: It fits the category of strong yet light with tensile strength ranging from 210–260 MPa (H32 temper).
- Lightweight: Lower weight: with a density of only 2.68 g/cm³, these framing members have an outstanding strength-to-weight ratio ideal for weight-conscious applications.
- Thermal and Electrical Conductivity: The material has good thermal conductivity (138 W/m·K) and an electrical conductivity of 35% IACS, thus becoming a sound choice for heat exchangers and electrical components.
- Non-Heat-Treatable: Strengthened by cold working instead of heat treatment so that mechanical properties would remain stable.
AA 5052 (EN AW-5052) Aluminum Alloy Technical Specifications
| Element | Composition (%) |
|---|---|
| Silicon (Si) | 0.25 max |
| Iron (Fe) | 0.40 max |
| Copper (Cu) | 0.10 max |
| Manganese (Mn) | 0.10 max |
| Magnesium (Mg) | 2.2 - 2.8 |
| Chromium (Cr) | 0.15 - 0.35 |
| Zinc (Zn) | 0.10 max |
| Others (each) | 0.05 max |
| Others (total) | 0.15 max |
| Aluminum (Al) | Remainder |
| Property | Value (H32 Temper) |
|---|---|
| Tensile Strength | 228 MPa min |
| Yield Strength | 193 MPa min |
| Elongation | 12% min (in 50mm) |
| Brinell Hardness (HB) | 60 HB min |
| Shear Strength | 138 MPa min |
| Fatigue Strength | 117 MPa min |
| Modulus of Elasticity | 70 GPa |
| Property | Value |
|---|---|
| Density | 2.68 g/cm3 |
| Melting Point | 607–649°C (1125–1200°F) |
| Thermal Conductivity | 138 W/m·K |
| Electrical Conductivity | 34% IACS |
| Thermal Expansion | 23.8 µm/m·°C (20–100°C) |
| Specific Heat Capacity | 0.880 J/g·°C |
- ASTM: B209
- UNS: A95052
- EN / DIN: EN AW-5052 / AlMg2.5
- JIS: A5052
- BS: N4
- AFNOR: A-G2.5
Common Applications of AA 5052 (EN AW-5052) Aluminum Alloy
Marine Industry
Construction and Architecture
Industrial Equipment
Consumer and Transportation Goods
-
AA 5052 (EN AW-5052) Aluminum Alloy Plate Customization
Types of tailoring beyond conventional stock to process Aluminum Alloy Plate AA 5052 (EN AW-5052):
Custom Dimensions: Precisely cut in widths, lengths, and shapes according to design and application specifications.
Thickness Range: Offered in thicknesses ranging from 0.5 mm to 150 mm, and so covers an enormous array of applications.
Surface Finish: It is available in mill finish, anodized finish, brushed finish, or coated finish to augment the looks and performance of the finish.
Processing Services: Together with precision cutting, CNC machining, forming, welding, and custom fabrication services, we supply ready-to-install components to suit your project needs.
Do contact our technical team today for a discussion about your custom fabrication needs and create a perfect solution for your application!
Contact Us
Premium aluminum plating grades include 5052 in the international classification. The AA 5052 Aluminum Alloy Sheet is what brings the crème de la crème of materials for your projects. Corrosion resistance, strength, and such versatile applications characterize this aluminum alloy. AA 5052 is the most dependable alloy in performance and durability throughout demanding places, be they marine, industrial, commercial or domestic.
Let us be your partner — with an abundance of stock and very fine processing works — in order to guide you with solutions tailored specifically for your needs. From standard AA 5052 sheets to specially engineered components, let us assist you in achieving utmost precision along with excellence in your projects.
